400W Watts MWT Solar Panels Manufacturing Plant
  • 400W Watts MWT Solar Panels Manufacturing Plant

400W Watts MWT Solar Panels Manufacturing Plant

Place of Origin Jiangsu, China
Brand Name AKS
Certification CGC,ISO9001:2015,TUV SUD,PV,CNAS,
Model Number QHES
Product Details
Product Name:
MWT Flexible Solar Panles
Model Number:
QHES
Cell Size:
126(21x6)
Panel Efficiency:
21.8 %
Installation Module Dimension:
1840mmx1040mmx2.5mm
Brand Name:
Sunport
Encapsulant:
POE
Highlight:

400W Watts Sunport Solar Panels

,

400W Watts Solar Panels Manufacturing Plant

,

MWT Solar Panels Manufacturing Plant

Payment & Shipping Terms
Minimum Order Quantity
1
Price
To be negotiated
Packaging Details
pallet
Delivery Time
To be negotiated
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
200000 Watt/Watts per Week
Product Description

Sunport 400W Watts Flexible MWT Technology Sun Power Solar Power Module Soft Solar Panels Manufacturing Plant

Monocrystalline solar panels are known for their durability and long lifespan, which is another significant advantage. These panels are made from high-quality materials and manufacturing processes, ensuring that they can withstand harsh weather conditions and maintain their performance over time. The typical lifespan of monocrystalline solar panels is around 25-30 years, making them a worthwhile investment for those who want a reliable and long-lasting renewable energy source. This extended lifespan also means that monocrystalline solar panels contribute to reducing waste and promoting sustainability in the long run.
Electrical Characteristics at Standard Test Conditions(STC)
Spec/Model Unit SPP365QHES SPP370QHES SPP375QHES SPP380QHES SPP385QHES
Max-Power(Pm) W 365 370 375 380 385
Power Tolerance W 0~+5
Max-Power Voltage(Vm) V 34.9 35.1 35.3 35.5 35.7
Max-Power Current(lm) A 10.46 10.54 10.62 10.7 10.78
Open-Circuit Voltage(Voc) V 42.4 42.6 42.8 43 43.2
Short-Circuit Current(lsc) A 11.09 11.16 11.23 11.3 11.35
Module Efficiency(qm) % 20.7 21 21.2 21.5 21.8


400W Watts MWT Solar Panels Manufacturing Plant 0400W Watts MWT Solar Panels Manufacturing Plant 1400W Watts MWT Solar Panels Manufacturing Plant 2



TECHNOLOGY COMPARISON
Compared with conventional module, MWT modules reduce 3% shaded area with no busbars. MWT module technology replaces string ribbon by conductive back sheet, abandoning strain, micro-crack and results power degradation, greatly improving stability and reliability.

— Structural Feature —
400W Watts MWT Solar Panels Manufacturing Plant 3
MWT
Positive and negative electrodes are both on the rear side of solar cell
400W Watts MWT Solar Panels Manufacturing Plant 4
Conventional
Positive and negative electrodes are located on opposite sides of the cell
— Cell Structure —
400W Watts MWT Solar Panels Manufacturing Plant 5
MWT
Busbar-free design exhibits higher power output by decreasing shading area up to 3 %
400W Watts MWT Solar Panels Manufacturing Plant 6
Conventional
Conventional design covers more cell surface from the main busbars, therefore the power output is limited
— Module Encapsulation —
400W Watts MWT Solar Panels Manufacturing Plant 7
Replace conventional soldering with conductive foil and 2D encapsulation structure
400W Watts MWT Solar Panels Manufacturing Plant 8
Conventional Cells connected by string ribbons

400W Watts MWT Solar Panels Manufacturing Plant 9

400W Watts MWT Solar Panels Manufacturing Plant 10400W Watts MWT Solar Panels Manufacturing Plant 11
