Trina Solar Panel
>
|
| Place of Origin | Jiangsu, China |
| Brand Name | AKS |
| Certification | CGC，ISO9001:2015，TUV SUD，PV，CNAS， |
| Model Number | TSM-DEG21C.20 |
Aesthetically, mono facial solar panels offer a sleek and modern appearance due to their uniform black color, which is a result of the single crystal structure. This visual appeal can be an important factor for those who want their solar panels to blend seamlessly with their property's design and contribute to its overall aesthetic value.
➤ Lower LCOE (Levelized Cost Of Energy), reduced BOS (Balance of System) cost, shorter payback time
➤ Lowest guaranteed first year and annual degradation;
➤ Designed for compatibility with existing mainstream system components
| Model No. | 645 | 650 | 655 | 660 | 665 |
| Warranty | |||||
| Product Warranty | 12 Years | ||||
| Power Warranty | 30 Years of 85% Output Power | ||||
| Electrical Data at STC | |||||
| Maximum Power (Pmax) | 645 Wp | 650 Wp | 655 Wp | 660 Wp | 665 Wp |
| Voltage at Maximum Power (Vmpp) | 37.5 V | 37.7 V | 37.9 V | 38.1 V | 38.3 V |
| Current at Maximum Power (Impp) | 17.23 A | 17.27 A | 17.31 A | 17.35 A | 17.39 A |
| Open Circuit Voltage (Voc) | 45.3 V | 45.5 V | 45.7 V | 45.9 V | 46.1 V |
| Short Circuit Current (Isc) | 18.31 A | 18.35 A | 18.4 A | 18.45 A | 18.5 A |
| Panel Efficiency | 20.80% | 20.90% | 21.10% | 21.20% | 21.40% |
| Power Tolerance (Positive) | 1% | 1% | 1% | 1% | 1% |
| Standard Test Conditions (STC): air mass AM 1.5, irradiance 1000W/m2, cell temperature 25°C | |||||
| Electrical Data at NOCT | |||||
| Maximum Power (Pmax) | 488 Wp | 492 Wp | 495 Wp | 499 Wp | 504 Wp |
| Voltage at Maximum Power (Vmpp) | 34.9 V | 35.1 V | 35.2 V | 35.4 V | 35.6 V |
| Current at Maximum Power (Impp) | 13.98 A | 14.01 A | 14.05 A | 14.1 A | 14.16 A |
| Open Circuit Voltage (Voc) | 42.7 V | 42.9 V | 43 V | 43.2 V | 43.4 V |
| Short Circuit Current (Isc) | 14.75 A | 14.79 A | 14.83 A | 14.87 A | 14.91 A |
| Temperature | 43±2 °C | ||||
| Nominal Operating Cell Temperature (NOCT): 800W/m2, AM 1.5, windspeed 1m/s,ambient temperature 20°C | |||||
| Thermal Ratings | |||||
| Operating Temperature Range | 40~85 °C | ||||
| Temperature Coefficient of Pmax | 0.34 %/°C | ||||
| Temperature Coefficient of Voc | 0.25 %/°C | ||||
| Temperature Coefficient of Isc | 0.04 %/°C | ||||
| Maximum Ratings | |||||
| Maximum System Voltage | 1500 V | ||||
| Series Fuse Rating | 35 A | ||||
| Material Data | |||||
| Panel Dimension (H/W/D) | 2384x1303x35 mm | ||||
| Weight | 38.7 kg | ||||
| Cell Type | Bifacial | ||||
| Cell Number | 132 | ||||
| Glass Type | Anti-reflection Coating, Tempered | ||||
| Glass Thickness | 2 mm | ||||
| Encapsulant Type | EVA | ||||
| Frame Type | Anodized Aluminium Alloy | ||||
| Junction Box Protection Class | IP 68 | ||||
| Connector Type | MC4 | ||||
| Cable Crossection | 4 mm2 | ||||
➤15 year product warranty
➤ 25 year performance warranty with lowest degradation;
➤Minimized micro-cracks with innovative non-destructive cutting technology
➤Ensured PID resistance through cell process and module material control
➤Mechanical performance up to 6000 Pa positive load and 4000 Pa negative load
