| Place of Origin | Jiangsu, China |
| Brand Name | AKS |
| Certification | CGC，ISO9001:2015，TUV SUD，PV，CNAS， |
| Model Number | M10-108-H-F |
TW Solar 390W 395W 400W 405W 410W 415W Fast Delivery Mono Solar Panels Half Cell Solar Panel Solar Panel
TongWei Solar offers a range of mono solar panels with power outputs including 390W, 395W, 400W, 405W, 410W, and 415W. These panels are designed to provide efficient and reliable solar energy solutions for various applications. Here is a product description for TongWei Solar's mono solar panels with the mentioned power outputs:
Monocrystalline Technology: TongWei Solar utilizes high-quality monocrystalline silicon cells in their mono solar panels. Monocrystalline technology ensures efficient conversion of sunlight into electricity, maximizing the overall performance and power output of the panels.
High Efficiency: TongWei Solar's mono solar panels are designed to achieve high conversion efficiencies. The advanced cell technologies and manufacturing processes employed by TongWei Solar contribute to improved light absorption and electron capture, resulting in higher overall efficiency and energy yield.
Durability and Weather Resistance: TongWei Solar's panels are built to withstand various environmental conditions, ensuring long-term durability and performance. They undergo rigorous testing for factors such as moisture resistance, temperature fluctuations, and potential-induced degradation to ensure reliable operation over the panel's lifespan.
| Model No. | TW400MAP-108-H-F | ||||
| Warranty | |||||
| Product Warranty | 15 Years | ||||
| Power Warranty | 25 Years of 84.8% Output Power | ||||
| Maximum Power (Pmax) | 400 Wp | 405 Wp | 410 Wp | 415 Wp | 420 Wp |
| Voltage at Maximum Power (Vmpp) | 30.58 V | 30.73 V | 30.88 V | 31.03 V | 31.18 V |
| Current at Maximum Power (Impp) | 13.08 A | 13.18 A | 13.28 A | 13.38 A | 13.47 A |
| Open Circuit Voltage (Voc) | 37.08 V | 37.23 V | 37.38 V | 37.53 V | 37.68 V |
| Short Circuit Current (Isc) | 13.77 A | 13.87 A | 13.92 A | 13.95 A | 13.98 A |
| Panel Efficiency | 20.50% | 20.70% | 21% | 21.30% | 21.50% |
| Power Tolerance (Positive) | 1% | 1% | 1% | 1% | 1% |
| Standard Test Conditions (STC): air mass AM 1.5, irradiance 1000W/m2, cell temperature 25°C | |||||
| Electrical Data at NOCT | |||||
| Maximum Power (Pmax) | 302.8 Wp | 306.6 Wp | 310.3 Wp | 314.1 Wp | 317.9 Wp |
| Voltage at Maximum Power (Vmpp) | 28.76 V | 28.9 V | 29.04 V | 29.18 V | 29.32 V |
| Current at Maximum Power (Impp) | 10.52 A | 10.6 A | 10.68 A | 10.76 A | 10.84 A |
| Open Circuit Voltage (Voc) | 34.72 V | 34.86 V | 35 V | 35.15 V | 35.29 V |
| Short Circuit Current (Isc) | 10.82 A | 10.9 A | 10.97 A | 11.05 A | 11.12 A |
| Temperature | 45±2 °C | ||||
| Nominal Operating Cell Temperature (NOCT): 800W/m2, AM 1.5, windspeed 1m/s,ambient temperature 20°C | |||||
| Thermal Ratings | |||||
| Operating Temperature Range | 40~85 °C | ||||
| Temperature Coefficient of Pmax | 0.34 %/°C | ||||
| Temperature Coefficient of Voc | 0.27 %/°C | ||||
| Temperature Coefficient of Isc | 0.045 %/°C | ||||
| Maximum Ratings | |||||
| Maximum System Voltage | 1500 V | ||||
| Series Fuse Rating | 25 A | ||||
| Material Data | |||||
| Panel Dimension (H/W/D) | 1722x1134x30 mm | ||||
| Weight | 20.5 kg | ||||
| Cell Type | Monocrystalline | ||||
| Cell Number | 108 | ||||
| Glass Type | Anti-reflection Coating, Tempered | ||||
| Glass Thickness | 3.2 mm | ||||
| Frame Type | Anodized Aluminium Alloy | ||||
| Junction Box Diodes | 3 | ||||
| Junction Box Protection Class | IP 68 | ||||
| Connector Type | MC4 | ||||
| Cable Crossection | 4 mm2 | ||||
