615W Huasun Solar Panels 620W 625W 630W 635W Black Aluminium Frame Solar Panel
  • 615W Huasun Solar Panels 620W 625W 630W 635W Black Aluminium Frame Solar Panel
  • 615W Huasun Solar Panels 620W 625W 630W 635W Black Aluminium Frame Solar Panel
615W Huasun Solar Panels 620W 625W 630W 635W Black Aluminium Frame Solar Panel

615W Huasun Solar Panels 620W 625W 630W 635W Black Aluminium Frame Solar Panel

Place of Origin Jiangsu, China
Brand Name AKS
Certification CGC，ISO9001:2015，TUV SUD，PV，CNAS，
Model Number G12-120-DS
Product Details
Brand Name:
Huasun
Max. Power:
635W
Material:
Monocrystalline Silicon
Power Range:
615W-635W
Number Of Cells:
120 Cells
Customization:
Customized Logo(Min. Order 100000 Watts) Customized Packaging(Min. Order 100000 Watts) Graphic Customization(Min. Order 100000 Watts)
Type:
PERC, Half Cell, Bifacial, HJT
Panel Efficiency:
22.44%
Certificate:
IEC/TUV/CE
Panel Dimensions:
2172x1303x35mm
Cell Size:
210*210mm
High Light:

615W Huasun Solar Panels

,

Huasun Solar Panels 620W

,

635W Black Aluminium Frame Solar Panel

Payment & Shipping Terms
Minimum Order Quantity
30pcs
Price
To be negotiated
Packaging Details
pallet
Delivery Time
To be negotiated
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
200000 Watt/Watts per Week
Product Description

HUASUN 615W 620W 625W 630W 635W Pv Panels System Black Aluminium Frame Placa Solar

In traditional glass-backsheet solar panels, only the front side of the solar cell is exposed to sunlight, and therefore only one side of the cell is active in generating electricity. However, in double-glass solar panels, both sides of the solar cell are exposed to sunlight, allowing for the capture of light from multiple angles. This bifacial design enables double-glass solar panels to generate electricity not only from direct sunlight but also from reflected light that reaches the rear side of the panel.


“Passivated Emitter and Rear Contact” solar cells, known as PERC solar cells, are becoming more common today as an option for making solar panels. PERC solar cells are modified conventional cells that enable the cells to produce 6 to 12 percent more energy than conventional solar panels.



Model Number
LR5-72HPH-540M
LR5-72HPH-545M
Testing Condition
STC
NOCT
STC
NOCT
Maximum Power(Pmax/W)
540
403.6
545
407.4
Open Circuit Voltage(Voc/V)
49.5
46.54
49.65
46.68
Short Circuit Current(lsc/aA)
13.85
11.2
13.92
11.25
Voltage at Maximum Power(Vmp/V)
41.65
38.69
41.80
38.83
Current at Maximum Power(Imp/A)
12.97
10.43
13.04
10.49
Module Efficiency(%)
20.9
21.1
Model Number
LR5-72HPH-550M
LR5-72HPH-555M
Testing Condition
STC
NOCT
STC
NOCT
Maximum Power(Pmax/W)
550
411.1
555
414.8
Open Circuit Voltage(Voc/V)
49.8
46.82
49.95
46.97
Short Circuit Current(lsc/aA)
13.98
11.31
14.04
11.35
Voltage at Maximum Power(Vmp/V)
41.95
38.97
42.10
39.11
Current at Maximum Power(Imp/A)
13.12
10.56
13.19
10.61
Module Efficiency(%)
21.3
21.5
Model Number
LR5-72HPH-560M


Testing Condition
STC
NOCT


Maximum Power(Pmax/W)
560
418.6


Open Circuit Voltage(Voc/V)
50.1
47.11


Short Circuit Current(lsc/aA)
14.1
11.4


Voltage at Maximum Power(Vmp/V)
42.25
39.25


Current at Maximum Power(Imp/A)
13.26
10.67







615W Huasun Solar Panels 620W 625W 630W 635W Black Aluminium Frame Solar Panel 0



615W Huasun Solar Panels 620W 625W 630W 635W Black Aluminium Frame Solar Panel 1



615W Huasun Solar Panels 620W 625W 630W 635W Black Aluminium Frame Solar Panel 2



615W Huasun Solar Panels 620W 625W 630W 635W Black Aluminium Frame Solar Panel 3

615W Huasun Solar Panels 620W 625W 630W 635W Black Aluminium Frame Solar Panel 4615W Huasun Solar Panels 620W 625W 630W 635W Black Aluminium Frame Solar Panel 5



FAQ
Q:Are you a factory or a trading company?
A:We are a professional Solar Panels Manufacturer in China
Q:How can we guarantee the products quality?
A:Always provide the esteemed buyer a pre-production sample before mass production; Always testing every product before despatching the shipments;
Q:What products we can supply you?
A:Solar Panel,Inverter,Mounting System,Battery,Pv Cable,Distributor Box,Pv Connector,Etc


Q:Can the products pricing be cheaper?
A:Of course, you will be offered a a very good discount with large quantities.
Q: Can print our company‘s logo on the pv panels?
A:Yes! And we accept the OEM&ODM orders.
